Detailed Explanation of Laser Welding Technology for Aluminum-Shelled Batteries

Prismatic lithium-ion batteries with square aluminum shells have become a key technology in the power battery field due to their stable structure, excellent impact resistance, high energy density, and large single-cell capacity. Currently, this type of battery holds a significant share of the power battery market and is widely used in new energy vehicles, energy storage systems, and industrial equipment. The battery structure typically consists of cells, electrolyte, casing, and top cover assembly. The casing is often made of high-strength aluminum alloy materials, such as prismatic cell cases or battery aluminum housings. This type of structure can improve the overall energy density of the system while ensuring battery safety.



Laser welding is a key process in battery manufacturing, mainly used for processes such as soft connection welding of cells, electrode welding, top cover sealing welding, and sealing nail welding. Compared to traditional welding methods, laser welding has advantages such as high energy density, high welding precision, small heat-affected zone, and high degree of automation, thus playing an irreplaceable role in the production of aluminum shell prismatic lithium-ion batteries. Meanwhile, with the development of the new energy industry, high-efficiency welding technology for aluminum alloy prismatic battery cases is also constantly being upgraded. I. Technological Characteristics of Laser Welding for Aluminum-Cased Batteries

Laser welding technology uses a high-energy-density laser beam to rapidly melt localized areas of metal, forming a molten pool that solidifies upon cooling. For thin-walled aluminum alloy structures such as prismatic cell aluminum shells, laser welding can achieve high-precision sealing connections while ensuring weld strength and airtightness.



In power battery production, the top cover sealing weld is one of the longest and most critical welds. Since the battery casing typically uses a lithium cell aluminum shell or lithium cell battery aluminum shell structure, the welding quality directly affects the battery's sealing performance, safety, and lifespan. Therefore, the development of welding technology mainly focuses on improving welding speed, reducing spatter, improving weld quality, and increasing production efficiency.







With the rapid development of the power battery industry, laser welding technology for aluminum-cased batteries has undergone several development stages. The technical characteristics of each stage are mainly reflected in welding speed, equipment structure, and welding stability.



1. Laser Welding Stage 1.0: Basic Automated Welding

In the early stages of power battery manufacturing, laser welding equipment primarily used single-source fiber lasers, with welding speeds typically below 100 mm/s. The equipment used a servo system to drive the welding head along the welding trajectory of the battery casing to complete the top cover sealing weld. The equipment at this stage had a relatively simple structure, suitable for initial production capacity needs, and could meet the basic welding requirements for aluminum shells for lithium-ion battery cells.



Due to the relatively low welding speed, the molten pool had a longer thermal cycling time, allowing the molten metal to flow and solidify fully, resulting in a generally smooth and consistent weld surface. For energy storage battery casing structures, such as aluminum shells for lithium iron phosphate cells, this stage of technology demonstrated relatively reliable stability.



However, with the rapid growth in demand for power batteries, low-speed welding gradually became insufficient to meet production capacity requirements. As welding speeds increased further, problems such as spatter, porosity, and unstable welds easily arose, prompting the industry to explore new technological solutions.



2. Laser Welding 2.0 Stage: High-Speed ​​Welding Technology

With the rapid expansion of the power battery market, production line capacity demands have significantly increased, leading to welding speeds gradually rising to 150–200 mm/s. To meet the requirements of high-speed welding, equipment structures have been upgraded, with linear motor drive systems gradually replacing traditional servo drives, thus achieving more stable welding trajectory control.



In this stage, the industry began researching various process solutions to meet the welding needs of New Energy Vehicle Aluminum Battery Cases. For example, welding quality was optimized by adjusting the laser spot size, laser power, and welding parameters. Simultaneously, some studies proposed multi-laser composite welding schemes, using different beam combinations to improve weld penetration and weld width, thereby improving welding stability.



Furthermore, high-frequency oscillating welding technology was also applied in this stage. This technology controls the laser beam to oscillate at high frequency during the welding process, creating a dynamic rotating structure in the welding keyhole, thereby improving the flow state of the molten pool. This method effectively reduces weld porosity, improves weld uniformity, and enhances the welding process's adaptability to assembly errors, offering significant advantages for complex battery components such as Battery Packs with Aluminum Housings.



3. Laser Welding 3.0 Stage: Ultra-High-Speed ​​Welding Technology

With continuous advancements in laser technology, new high-power fiber lasers can output special spot shapes, such as point-ring composite beam structures. These beams achieve deep penetration welding through a central high-energy spot, while the outer ring beam provides additional heat input, thereby expanding the heat-affected zone and stabilizing the molten pool structure.



This technology further increases welding speeds to 300 mm/s while maintaining high weld quality. For high-precision aluminum shell structures such as Deep Drawn Aluminum Battery Housings, this solution can significantly improve production efficiency while ensuring welding stability.



Furthermore, point-ring beam technology offers good process compatibility. By adjusting the laser power distribution and spot pattern, it can adapt to the welding requirements of shells of different thicknesses, thus enabling its widespread application in the production of Pack Aluminum Housings and other multi-specification battery shells.







Laser welding technology offers several advantages in aluminum-cased battery manufacturing:



First, the concentrated energy of laser welding enables high-precision welding and reduces the heat-affected zone, thus maintaining the structural strength and dimensional stability of the aluminum shell for prismatic lithium-ion batteries.



Second, it boasts a high degree of automation, allowing for high integration with battery production lines, enabling large-scale production, and improving overall production efficiency.



Furthermore, laser welding provides excellent airtightness control, which is particularly important for battery structures requiring strict sealing, such as aluminum alloy prismatic battery cases.



Finally, the application of high-speed welding technology significantly reduces production costs, making battery aluminum housings more widely used in power batteries and energy storage systems.







With the continuous development of the new energy industry, aluminum-cased battery manufacturing technology will continue to evolve towards higher efficiency, higher stability, and higher automation. Future laser welding equipment will further increase welding speed while optimizing welding quality through intelligent control systems.



Simultaneously, battery structural design will continue to be optimized, for example, with thinner-walled structures, higher-strength materials, and more complex casing shapes. These changes will drive the continuous upgrading of welding technologies for prismatic cell aluminum shells and lithium cell aluminum shells to meet the manufacturing demands of higher-performance power batteries.





The development of laser welding technology has greatly promoted the large-scale production of prismatic aluminum-cased batteries. From early low-speed welding to high-speed oscillating welding, and then to spot-ring beam ultra-high-speed welding technology, welding efficiency and quality have been continuously improved, providing a key manufacturing foundation for the power battery and energy storage battery industries.



With the continued growth of the new energy vehicle and energy storage industries, the demand for high-performance aluminum shells for lithium-ion battery cells and new energy vehicle aluminum battery cases will further expand, and laser welding technology will play an even more important role in future battery manufacturing systems.
