Ceramic For Electric And Hybrid Vehicle Fuses
Products Description
The Ceramic for Electric and Hybrid Vehicle Fuses is a high-purity alumina-based engineering ceramic tube or outer structure. Its main function is to act as the insulating shell of the fuse, encapsulating the fusible element, the quartz sand arc-extinguishing medium, and terminal components to form a complete protection unit. The product is white, with a smooth or glazed surface, and possesses high hardness, high insulation strength, and excellent thermal stability.
Compared to traditional plastic or glass materials, the ceramic body performs exceptionally well in high-voltage direct current (DC) environments, able to withstand the instantaneous high temperatures of an electric arc without cracking or carbonising, and effectively preventing arc leakage and high-temperature material splashing. Essentially, it is the "safety skeleton" and "insulation barrier" of the fuse system, indispensable in high-energy-density applications such as fast charging of new energy vehicles, high-voltage platforms, and photovoltaic energy storage.
Design Advantages: Designed for High-Voltage Arc Extinguishing Environments
Inner Wall Roughness Control
Optimised inner wall surfaces facilitate uniform filling of the arc-extinguishing filler (such as silica sand) and enhance interfacial bonding during arc ejection.
End Stress Relief
Finely chamfered EV Fuse Ceramic Body nozzles reduce the risk of edge chipping during assembly and optimise sealing performance.
Customizable Structure
Supports irregular cavity designs, adapting to the layout requirements of different internal structures such as fast-melting and time-delay fuses.
Key Functions and Product Advantages: Constructing an Insurmountable Safety Line
| The Ultimate Line of Defence for Explosion-Proof Containment | Under extreme short-circuit breaking (e.g., above 100kA), the Ceramic Body for EV Fuse body, with its extremely high compressive strength and thermal shock resistance, effectively traps the plasma shock wave and high-temperature molten metal droplets generated by the vaporisation of the molten metal within the cavity, preventing secondary disasters caused by fuse explosion to the battery pack or distribution cabinet. |
| The Enduring Commitment of Insulation | Under the long-term high-voltage vibration of new energy vehicles and the harsh temperature cycling of photovoltaic and energy storage systems, the Ceramic Body for Electric Vehicle Auxiliary Fuse's non-ageing and non-degrading insulation properties ensure absolute isolation between the two poles, eliminating the risk of leakage and tracking that may occur over time due to organic materials. |
| High-efficiency conductor for arc extinguishing energy | Through precise cavity design, it guides the high-temperature electric arc to undergo intense heat exchange with the quartz sand, accelerates the cooling and extinguishing of the arc, significantly shortens the arcing time, and reduces the Joule integral (I²t) generated when the fuse breaks, thereby protecting the sensitive power electronic devices in the downstream stage from overload thermal damage. |
Intelligent Manufacturing Assurance and Quality System
We deeply understand the importance of zero redundancy in safety. Every ceramic component adheres to the following standards:
IATF 16949 Certification: Strictly following the automotive industry's quality management system.
Batch Traceability: From raw material arrival to finished product shipment, all process parameters are digitally traceable.
Materials Reliability Laboratory: Equipped with internal thermal shock, breakdown voltage, and mechanical stress laboratories, providing customers with detailed technical data support.
contact us
We not only provide standardised Ceramic Tube for EV Charger Fuse Links but also offer integrated engineering support, from material optimisation and structural development to stable mass production, tailored to customers' fuse structure, assembly processes, and high-voltage application needs, helping projects achieve long-term delivery with higher reliability.
